Technical data of Linear Units LTZ50 from Lineairtechniek



    LTZ50-TR-S15D*
Maximum stroke mm 5.730
Maximum speed mm/s  3.000
Maximum acceleration m/s2 30
No load torck Nm 1,1
Repeatability mm ±0,1
Movment per revolution mm 100

Weights Linear Units
Unit weight 0 mm stroke Kg 2,53
Weight per 100 mm stroke Kg 0,28

​Load capacity
Mx  Nm 106
My  Nm 106
Mz Nm 40
Fx   N 1.000
Fy N 3.400
Fz N 3.600

*D Double carriage





LTZ50-TR-S15D

LTZ50-TR-S15D
