Technical data of Lineair Unit LTi60 from Lineairtechniek


    LTi60-TRB-C45
Maximum stroke mm 2.300*
Maximum speed mm/s 1.500
Maximum acceleration m/s2 30
No load torck Nm 0,2
Repeatability mm ±0,1
Movement per revolution mm 200

Weight Linear Unit
Unit weight 0 mm stroke  Kg 5,00
Weight per 100 mm stroke Kg 0,40
Mass of carriage  Kg 0,70

Load capacity
Mx  Nm 80
My  Nm 120
Mz Nm 8
Fx N 2.100
Fy N 1.600
Fz N 860

*longer lengths on request

LTi60-TRB-C45-

LTi60-TRB-C45-
